To prevent dust and little curious fingers from getting into the electronics. Easy enclose the cabinet. However, the electronics can also get warm, so a cooling system is needed. I decided on a passive ventilation system has intake vents at the front above the kick board, and outtake vents at the top of the back panel. Air goes in and out in a linear fashion. At least in theory... but I think it's a good theory. The mesh is 5mm woven stainless steel.
Tuesday, June 23, 2015
Here's a few photos of my first attempt at preparing the timber in for the HiFi project. It was the first time resawing wide boards on the new bandsaw. Worked well until a change in the weather rendered some of the boards closer to bowel than a board. These panels that would meant to be for the cse will we re-worked as shelves and rear panel.
Friday, April 3, 2015
In November 2010 I first posted about building a wood rack for long lumber. Well... 4 1/2 years later the project never got off the ground, so I took a different strategy. Down to Bunnings for some metal shelving. I'm using 3 x 900mm wide 2.1m tall shelving units. There are lots of advantages to this system - quick (took less than 2 hours to buy and install), easy inspection and access, termite proof, and eacg shelf rated at 750kg. Wasn't cheap though.
Tuesday, February 3, 2015
The planer / thicknesser combo was an easier tune up. I purchased some new blades from carbatec (took over 2 months to arrive, despite me checking that they were in stock before ordering). The old blades I have had sharpened locally. Always a little tricky to level the three blades which are suspended by 12 springs and 15 bolts.
The current HiFi project requires some 50mm timber resawed and machined to 18mm. Assuming the bandsaw was still in top condition after more than a year since serious use... was a mistake. The first resaw job looked like I was making shingles with a beautiful cut at the top and a wedge at the bottom. The culprits were a combination low blade tension and the lower blade guide having come loose. It was a good excuse to take it all about and give a clean. Immediate rewards from a little maintenance with the remainder of the cuts working well.
